All parts of the machine is made of AISI 304 Cr-Ni Stainless Steel.
Operates with NG (Naturel Gas) or LPG (Liquid Petrolum Gas).
MELTEM ® burners are used.
Safety System gas valves cut off the gas automatically when the burners go out.
Motor can be rotated at 1 r.p.m. to the right or left.
Motor is air-cooled and protected by heat shield.
Protective wires are made of AISI 310 Cr-Ni (heat-resisting) quality stainless steel, and they are durable.
Easy to perform general maintenance, repair and cleaning.
Opportunity to zoom in and remove meat thanks to movable skewer holder
Poured oil can be leached by perforated tray
The walking body ensures ease of operation
| Technical Specifications | |||||
| MODEL | MD-3 | MD-4 | MD-5 | MD-4K | |
| A-Width | cm | 52 | 52 | 57 | 52 |
| B-Depth | cm | 55 | 55 | 60 | 55 |
| C-Height | cm | 96 | 112 | 128 | 112 |
| D-Max. Height of meat | cm | 50 | 65 | 80 | 65 |
| Cooking Capacity | Kg | 40 | 70 | 120 | 70 |
| Gas Inlet | Inch | 1/2" | |||
| Electric Lolet | V | 230 V AC 50 Hz (115 V AC 60 Hz) | |||
| Type of Burner | MELTEM R-3 | ||||
| Burner | Pcs | 3 | 4 | 5 | 4 |
| Net Weight | Kg | 31 | 34 | 42 | 34 |
| Power | Kw | 9,7 | 12,9 | 16,1 | 12,9 |
