All parts of the machine is made of AISI 304 Cr-Ni Stainless Steel.
Motor is air-cooled and protected by heat shield.
Motor can be rotated at 1 r.p.m to the right or left.
Resistance bricks are made of cordierite ceramics.
Easy to perform general maintenance, repair and cleaning.
Utilized INCOLOY 800 tube resistance.
Technical Specifications | ||||
MODEL | ME-4 | ME-6 | ME-7 | |
A-Width | cm | 44 | 44 | 44 |
B-Depth | cm | 55 | 55 | 55 |
C-Height | cm | 87 | 110 | 127 |
D-Max.Height of meat | cm | 50 | 65 | 80 |
Max. Weight of meat | Kg | 30 | 50 | 70 |
Electric Lolet | V | 380 V AC 50 Hz (230 V AC 60 Hz) | ||
Resistance | Pcs | 4 | 6 | 7 |
Net Weight | Kg | 30 | 42 | 50 |
Power 1 | Kw | 6,5 | 9,6 | 11,2 |
Power 2 | Kw | 7,6 | 11,4 | 13,3 |
